PEMF therapy in the treatment of canine osteoarthritis: preliminary results
S. Pinna, DVM, PhD, A.M. Tribuiani, DVM, E. Pizzuti, DVM, A. Venturini, DVM Clinical Veterinary Department, Alma Mater Studiorum, University of Bologna, Ozzano Emilia (Bologna), Italy
The purpose of this study is to evaluate the analgesic and anti-inflammatory effects of the pulsed electromagnetic field (PEMF) in the treatment of osteoarthritis (OA) in dogs. The effectiveness of the PEMF therapy has been demonstrated by several experimental and clinical studies. In fact, while it is widely used in humane field1 , up to now, as far as dogs are concerned, only a few physical therapy reports have been published2,3. PEMF employs low frequency non-ionized athermic pulsed electromagnetic fields. It is assumed that, due to its interaction with the membrane channels, PEMF alters the transport of ions, like calcium, and causes a consequent modification of the membrane potential. This induces the fall of transduction signals which stimulate the synthesis of growing factors, important for bone and cartilage formation1,4. PEMF chondroprotective action is both direct, by means of homeostasis and articular metabolism modulation, and indirect due to its anti-inflammatory properties. Some trials demonstrated that PEMF increases chondrocytes proliferation and extracellular matrix components synthesis, while reducing OA progression5,6. Its anti-inflammatory properties are mediated by an agonist activity on adenosin receptors as well as by an inhibition of prostaglandines synthesis7 . PEMF analgesic effect could either be the result of a direct effect on the brain waves, or a consequence of its capacity to affect the endogenous and exogenous opioids system8 . Furthermore, PEMF increases blood circulation and tissues oxygenation, and reduces pain, edema and hematoma1 .
MATERIALS AND METHODS
For this study, only dogs that had had lameness for at least four weeks were chosen. It was also required a radiographic evidence of OA in one or more joints. Other factors of exclusion were: systemic diseases, infectious arthritis, pregnancy, and treatments with anti-inflammatory drugs in the last two weeks. Owners were informed about the clinical survey as well as the physical and therapeutic characteristics of PEMF. They were asked to sign an informed consent, stating their obligation to bring their dogs to the veterinary hospital at least 3 times per week, for a total of 20 sessions. Besides, owners were asked not to give any anti-inflammatory drugs, nor to change their dogs dietary and environmental habits, and to report any health problems which might occur during the study period. For this purpose, 20 dogs of different breed -10 male and 10 female- were enrolled. The mean body weight±SD was 24.68±13.74 kg (range, 5.5 to 50 kg), the mean±SD age was 7.3±4.3 years (range, 9 mounths to 17 years). The OA joints were 27 (11 elbows, 8 knees, 5 hips, 2 shoulders and 1 carpus). Lameness, pain on manipulation and palpation, and range of motion were evaluated at the beginning of the therapy (T0), at the tenth session (T10), at the end (T20), and re-evaluated after 4 and 12 months. Radiographic exams at T0 and T20 were taken, to score the OA signs. At the same time questionnaires were submitted to the owners for the assessment of chronic pain and its impact on their dogs health-related quality of life on the basis of behavioral changes9 and the PEMF therapy level of satisfaction. Follow-up included clinical and radiographic examinations and questionnaires 4 and 12 months after treatment. Scoring was based on a scale of 0 (normal) to 4 (severe) for each variable, except for pain recorded as yes/no, and range of motion recorded as increased/decreased compared with contralateral joint. Dogs were lain on a pulsated magnetic field mat with cyclic frequency (3-22-250-500-750-1000 Hz) and 0.75 microT intensity for 10 minutes, and then a small pad was applied on the affected joint for 8 minutes.
The percentage of dogs with lame that improved by at least one grade was 85% at T10 and 90% at T20 (18 dogs out of 20) (significantly P<0.05). There was pain on manipulation on 77.8% (21 joints out of 27) at T0, it was so on 14.3% (3 joints out of 21) at T10 and on 9.5% at T20. The range of motion scores were improved on 18.5% (5 joints out of 27) at T20. The radiographic signs of OA were scored in all dogs (mean 3±1.04) at T0, but were not significantly (P>0.05) improved at T20 (2.96±1.09). POSTERS 06B) posterOK_05) poster 02/09/10 12.31 Pagina 679 Reprinted in IVIS with the permission of ESVOT Close this window to return to IVIS 15th Annual European ESVOT Congress – Bologna, Italy – 2010 WVOC 2010, Bologna (Italy), 15th – 18th S. Pinna September • 680 At 4 months all 18 dogs had maintained the benefits recorded at T20. At 12 months 11 dogs were examined, two of them (18.2%) showed lameness and pain. No significantly x-ray changes (P>0.05) were recorded. The owners reported improvement (vitality, appetite, lameness) in 45% of dogs at the 5th session. At T0 the owners questionnaire score was 1.07, at T10 it was decreased to 0.80, and at T20 it was significantly (P<0.05) improved to score 0.59. The owners’ satisfaction was scored 0.43 (0=high satisfaction, 4=unsatisfaction). No adverse effects were recorded during the treatment. CONCLUSION The majority of the dogs improved with PEMF treatment with respect to their baseline lameness and pain values, and this was already obvious at half therapy. The benefits were maintained for medium-long time without using anti-inflammatory drugs. We suppose that a mechanical block from osteophytes, recorded on x-ray films, could be the reason of the lack of improvement of the range of motion. It must be noted that immunohistochemistry trials on Guinea Pigs showed that PEMF treatment preserves the morphology of articular cartilage and retards the development of osteoarthritic lesions5,6. In contrast with what expected in the present study, the radiograph signs of OA were not decreased probably because 20 sessions were not sufficient to observe any x-rays changes of bone and cartilage. The results of questionnaires indicated that the decrease of pain impacted positively on the dogs health-related quality of life, and on their owners’ high grade of satisfaction. Double-blind, randomized, controlled studies of comparison between NSAID and PEMF efficacy could be a topic for further research. In conclusion, PEMF is a non-invasive remedy, lacking in adverse effect, easy to employ, and useful for controlling pain and inflammation associated with osteoarthritis.
1. Markov MS (2007). Pulsed electromagnetic therapy history, state of the art and future. Environmentalist DOI 10. 1007/s10669-007-9128-2. [http://www.curatronic.com/pdf/PEMFenvironmentalist.pdf].
2. Canapp DA (2007). Select Modalities. Clin Tech Small Anim Pract, 22,160-165.
3. Marcellin-Little DJ (2004). Benefits of physical therapy for osteoarthritic patients. Proceeding 12th ESVOT Congress, Munich, 10th-12th September, pp 100-103.
4. Trock DH (2000). Electromagnetic fields and magnets. Investigational treatment for musculoskeletal disorders. Rheum Dis Clin North Am 26,51-62.
5. Ciombor DM, Aaron RK, Wang S. Simon BB (2003). Modification of osteoarthritis by pulsed electromagnetic fielda morfological study. Osteoarthr Cartil 11,455-462.
6. Fini M, Torricelli P., Giavaresi G, et al (2008). Effect of pulsed electromagnetic field stimulation on knee cartilage, subchondral and epyphiseal trabecular bone of aged dunken Hartley guinea pigs. Biomed Pharmacother 62,709-715.
7. Varani K, De Mattei M, Vincenzi F, et al (2008). Characterization of adenosine receptors in bovine chondrocytes and fibroblast-like synoviocytes exposed to low frequency low energy pulsed electromagnetic fields. Osteoarthr Cartil 16,292-304.
8. Thomas AW, Graham K, Prato FS, et al (2007) A randomized, double-blind, placebo-controlled clinical trial using a low-frequency magnetic field in the treatment of musculoskeletal chronic pain. Pain Res Manag 12,249-258.
9. Wiseman-Orr ML, Scott EM, Reid J, et al (2006). Validation of a structured questionnaire as an instrument to measure chronic pain in dogs on the basis of effects on health-related quality of life. Am J Vet Res 67,1826-1836.
